Dual Source Energy Meter 010

उत्पाद वर्णन

Specification:
Display Parameters
Kwh & Average Kw - 6 Display Digits (1 Decimal Place)
Run Hours - 6 Display Digits
(2 Decimal Place)
Accuracy
Class: 1.0Three Phase four wire
Selection: Programmable through KeyPad
Dimension: 96mm(H) x 96mm(W) x 75mm(D)

Features Details
Mains kWh LED indication.
Calibration LED indication.
Current Resolution (Auto ranging) “ 0.01A / 0.1A / 1A.
Reverse LED indication.
CT Ratio Programming (CTR values 5, 10, 20, 25, 30, 50, 60, 75, 100, 125, 150, 200, 250, 300, 400, 500, 600, 800, 1000, 1200).
Bright Seven segment LED display for better readability.
Auto scrolling & Manual mode selectable.
RS485 communication (optional).
